FABRICS FOR THERMAL SHIELD

Texfire has developed a collection of flame retardant fabrics especially designed to perform as a thermal shield, with an aluminized side being able to block temperature transference proceeding from a radiant heat source or convective heat, maximizing their performance when they are detached from the heat source. In addition, they offer a good resistance in direct contact with flames.

Flame retardant fabrics of the thermal shield type are an excellent solution to protect and thermally insulate objects, surfaces and even to delimit areas before heat sources like ovens, engines, ducts or even fires, performing as a protection barrier and avoiding that thermal radiation crosses the fabric. They are widely used to manufacture PPEs in the foundry sector and also as a protection in other environments with extreme temperatures.

Texfire has designed this range of aluminized fabrics by combining several lamination technologies and different materials as a source fabric. These fabrics are not suitable for applications where there is a high abrasion risk, or where the fabric must bend or “wrinkle” several times on the same point, because they fall short of flexibility and elasticity.

Fiberglass aluminised fabric is thought to protect before temperature chances, oils and organic acids spills and industrial insulations.

Composition: 95% Fiberglass 5% Aluminium
Resistance: 260ºC in continuous
Weight: 200 g/m² ±5%
Width: 150 cm
Featured: Thermal isolation

Fiberglass aluminised fabric is thought to protect before temperature changes, oil and organic acid spills and industrial insulations..

Composition: 95% Fiberglass 5% Aluminium
Resistance: 550ºC
Weight: 430 g/m² ±5%
Width: 150 cm
Featured: Thermal isolation

It allows the insulation of radiant heat sources, the same time it offers good protection to small splashes of melted metal.

Composition: 82% E-glass 16% Silicone 2% Aluminium powder
Resistance: 350ºC in continuous
Weight: 510 g/m² ±5%
Width: 150 cm
Featured: Insulation of radiant heat and protection to small splashes of melted metal

Aluminized para-aramid fibre fabric with high mechanical, abrasion, cut and vibration resistance. With good behaviour against radiant and convective heat.

Composition: 100% Aluminized Recycled Para-Aramid
Resistance: 260ºC in continuous
Weight: 465 g/m² ±5%
Width: 150 cm
Featured: Insulation of convective, radiant or direct flame heat

Fabric composed of a layer of fiberglass together with an aluminum foil that protects from continuous radiant heat, and another layer of charred PAN carbonized fabric to expand its insulating characteristics.

Composition: 48% GL 44% PAN 8% AL
Weight: 450 g/m² ±5%
Width: 150 cm
Featured: Thermal insulation

Nonwoven of pre-oxidized fibers, has a layer of aluminium, that offers a high resistnace to passage of flames of fire.

Composition: 96% PAN 4% Aluminium
Resistance: 700ºC
Weight: 550 g/m² ±5%
Width: 150 cm
Featured: Insulation of convective, radiant or direct flame heat

Lightweight silica fabric aluminized on both sides for high temperatures. It offers excellent thermal stability and fire resistance.

Composition: 62% Silica, 38% Aluminium (alloy 1050)
Resistance: 850ºC continuous
Weight: 290 gr/m² ±5%
Width: 90 cm
Highlight: Thermal insulation

Aluminized silica fabric on one side with high mechanical and structural resistance, even when subjected to high temperatures.

Composition: 85% Silica 15% Aluminium (alloy 1050)
Resistance: 850ºC continuously
Weight: 400 gr/m ±5%
Width: 90 cm
Highlight: Thermal insulation
